- Class 0.5 energy metering accuracy (same as professional meters)
- Capable of bidirectional active energy and 4-quadrant reactive energy measurement
- Real-time monitoring of voltage, current, power, and other electrical parameters
- Support for manual/automatic control modes
- 8-level dynamic brightness adjustment
- Control based on latitude and longitude time zones
- Support for PWM and 0-10V (DALI) dimming output
- Utilizes WI-SUN wireless communication protocol
- Single gateway supports up to 5000 nodes
- Supports Over-The-Air (OTA) firmware upgrades, taking approximately 30-40 minutes
- Built-in leakage detection
- Built-in tilt detection
- Integrated temperature/humidity sensor
- Integrated accelerometer
- Integrated GPS module
- Real-time status monitoring and event reporting
- Operating voltage range: 154VAC-264VAC
- Maximum output: 120V/16A
- Standby power consumption as low as 0.2W
- Operating temperature range: -40°C to +85°C
- Protection rating: IP65
- Mean Time Between Failures (MTBF): ≥50,000 hours
- Service life: ≥15 years
| Vendor | Wasion Energy |
|---|---|
| Weight | 2.0 kg |
